Reproducible, High Yields with chemagic™ Automated or Manual Purification of Circulating Cell Free DNA
Circulating cell free DNA (cfDNA) in body fluids is being used for noninvasive, real-time biomarker research and more. Yet detection is often challenged by its low levels, fragmentation and preanalytical variabilities introduced by sample collection, plasma preparation, and nucleic acid purification.
PerkinElmer chemagen cfDNA extraction kits, together with dedicated chemagen instruments rely on patented chemagicTM technology using M-PVA Magnetic beads to ensure a high quality of nucleic acid purification. Comparable yields to manual spin column methods were obtained with efficient removal of contaminants and exclusion of cross-contamination. With automation, variabilities associated with multiple handling steps are reduced and sample integrity maintained with full sample tracking capabilities.
Benefits of automated cfDNA isolation with chemagicTM technology:
- Higher reproducibility and comparable yields to manual methods
- Fast, automated workflow with on-board lysis and no heating required
- Wide range of sample inputs applicable from 0.5 to 18 ml
- Full sample tracking with barcode reading and bidirectional LIMS communication capability
- Ability to isolate viral nucleic acids
- Suitable for fresh or frozen plasma/serum from EDTA, citrate or Streck® Cell-free DNA BCT® tubes
- Downstream compatibility with various assays - ddPCR, NGS, qPCR etc.
- Compatibility with other automated PerkinElmer systems
“The PerkinElmer cfDNA extraction kit on the chemagic 360 platform has greatly reduced the hands-on time needed for sample preparation. It has also given us improved cfDNA yields compared to the current, manual approach used in our laboratory and enabled significantly higher throughput. The ease-of-use of the system is high and has made it easy for us to rapidly train our staff and implement the approach in our day-to-day practice.”
Veli-Mikko Puupponen, CEO, BiopSense Oy/Ltd, Finland
Looking for a Manual Option?
If you do not have a chemagicTM instrument but would like to benefit from the advantage of chemagicTM M-PVA Magnetic Bead technology, the manual chemagicTM cfDNA 5k kit is now available. Process up to 5 ml of sample and avoid spillages and clogs linked to spin column or vacuum-based systems with an easy magnetic bead-based protocol.
Manual cfDNA Extraction with chemagic™ cfDNA 5k kit”
- 40 preps
- 1-5 ml plasma/serum input
- 30-100 µl elution volume
- 60-90 minutes processing time
Additional magnetic racks required, see Product Overview for Manual DNA Isolation for details
Product overview for Automated cfDNA isolation
|Catalog No.||Kit Name||Instrument||Samples/Batch||Preps/Kit||Sample Volumes||Processing Time|
Prime™ cfDNA 5k Kit H24
|chemagic Prime 4/8||24||240||3 - 5 ml||240 min|
cfDNA 5k Kit H24
|chemagic 360/MSM I||24||240||3 - 5 ml||100 min
(incl. 15 min hands-on time)
cfDNA 2k Kit H24
|chemagic 360/MSM I||24||240||1 - 2 ml||90 min
(incl. 15 min hands-on time)
cfDNA 10k Kit H24
|chemagic 360/MSM I||24||240||6-10 ml||115 min
(incl. 20 min hands-on time)
cfDNA 18k Kit H12
|chemagic 360/MSM I||12||Up to 250||10, 15 or 18 ml||125 min
(incl. 15 min hands-on time)
cfDNA 1.5k Kit H96
|chemagic 360/MSM I||96||960||0.5 - 1.5 ml||120 min
(incl. 30 min hands-on time)
*Additional accessories required: 3 quantity chemagic 13 mL Double Bottom Rack H24 (art. No. CMG-13005340)
Product overview for Manual cfDNA isolation
|Product No.||Kit Name||Accessories required|
Preps / Kit
|Sample Volumes||Processing Time|
|CMG-134||chemagic™ cfDNA 5k Kit||chemagic™ Stand 2 x 12|
chemagic Magnetic Stand Type F
chemagic cfDNA Stand 12 (Optional)
|1 - 5 ml||60-90 min (depending on user experience)|
Plasma Preparation Protocol
Best Practices in cfDNA Purification
Sample Collection & Plasma Preparation
To avoid contamination of cfDNA with genomic DNA from ruptured blood cells, it is recommended to prepare plasma as fresh as possible (within 24h after blood draw for EDTA tubes or longer for specialized cell free blood collection tubes, refer to tube manufacturer).
A double centrifugation protocol during plasma preparation is recommended to minimize the potential carry over of cells and genomic DNA (refer to tube manufacturer for max. centrifugation speeds). Special care should be taken to avoid transfer of any other blood components (buffy coat or red blood cells) when separating the plasma fraction.
From 10 ml of whole blood, approximately 4 - 5 ml plasma can be expected. For a guidance on how to prepare plasma for cfDNA analysis, please refer to manuals below.
cfDNA yields isolated from human plasma samples are typically in the range of 1 - 30 ng/mL of plasma and therefore critically low and maybe outside the detection parameters determined by spectrophotometric methods. If quantification of the extracted cfDNA is required, two methods are recommended: A PCR-based method (qPCR, ddPCR) and a fragment analysis assay where an internal reference is used, such as the LabChip® cfDNA assay. Quantification based on fluorometric method may lead to varying results dependent on various factors and therefore is not recommended. Likewise, fragment analysis methods based on upper marker peak size will lead to inaccurate quantitation and should be avoided. Please refer to manuals for more details.
|Catalog No.||Kit Name||PDF Protocol|
|CMG-134||chemagic™ cfDNA 5k Kit (manual)||Protocol CMG-134 chemagic cfDNA 5k Kit|
|CMG-1304||chemagic™ cfDNA 5k Kit H24||Protocol CMG-1304 chemagic cfDNA 5k Kit H24|
|CMG-1302||chemagic™ cfDNA 2k Kit H24||Protocol CMG-1302 chemagic cfDNA 2k Kit H24|
|CMG-1396||chemagic™ cfDNA 1.5k Kit H96||Protocol CMG-1396 chemagic cfDNA 1.5k Kit H96|
|CMG-1310||chemagic™ cfDNA 10k Kit H24||Protocol CMG-1310 chemagic cfDNA 10k Kit H24|
Contact us for further information
Frank, M. S., Andersen, C. S. A., Ahlborn, L. B., Pallisgaard, N., Bodtger, U., & Gehl, J. Circulating Tumor DNA Monitoring Reveals Molecular Progression before Radiologic Progression in a Real-life Cohort of Patients with Advanced Non–small Cell Lung Cancer. Cancer Research Communications, 2022; 2(10), 1174–1187.
Callesen LB, Hansen TF, Andersen RF, Pallisgaard N, Kramer S, Schlander S, Rafaelsen SR, Boysen AK, Jensen LH, Jakobsen A, Spindler KG. OPTIMISE: Optimisation of treatment selection and follow-up in oligometastatic colorectal cancer - a ctDNA-guided phase II randomised approach. Study protocol. Acta Oncol. 2022 Sep;61(9):1152-1156.
Kirchweger P, Kupferthaler A, Burghofer J, Webersinke G, Jukic E, Schwendinger S, Wundsam H, Biebl M, Petzer A, Rumpold H. Prediction of response to systemic treatment by kinetics of circulating tumor DNA in metastatic pancreatic cancer. Front Oncol. 2022 Aug 30;12:902177.
Kirchweger P, Kupferthaler A, Burghofer J, Webersinke G, Jukic E, Schwendinger S, Weitzendorfer M, Petzer A, Függer R, Rumpold H, Wundsam H. Circulating tumor DNA correlates with tumor burden and predicts outcome in pancreatic cancer irrespective of tumor stage. Eur J Surg Oncol. 2022 May;48(5):1046-1053.
Broholm M, Bojesen R, Gögenur M, Weinberger Rosen A, Watt S, Bulut M, Vogelsang R, Quist Jensen H, Orhan A, Bjerrum E, Søs Auður Andersen C, Pallisgaard N, Litman T, Troelsen JT, Gögenur I. Circulating Cell-Free DNA and Systemic Inflammatory Response after Self-Expandable Metal Stent for Malignant Bowel Obstruction. Archives of Microbiology and Immunology 6 (2022): 247-255.
Lefèvre AC, Pallisgaard N, Kronborg C, Wind KL, Krag SRP, Spindler KG. The Clinical Value of Measuring Circulating HPV DNA during Chemo-Radiotherapy in Squamous Cell Carcinoma of the Anus. Cancers (Basel). 2021 May 18;13(10):2451.
Yu J, Cho E, Choi J, Lim JE, Lee J, Kang M, Sung HH, Jeong BC, Seo SI, Jeon SS, Lee HM, Jeon HG. Genomic mutation profiling using liquid biopsy in Korean patients with prostate cancer: Circulating tumor DNA mutation predicts the development of castration resistance. Investig Clin Urol. 2021 Mar;62(2):224-232.
Moon SM, Kim JH, Kim SK, Kim S, Kwon HJ, Bae JS, Lee S, Lee HS, Choi MY, Jeon BH, Jeong BH, Lee K, Kim HK, Kim J, Um SW. Clinical Utility of Combined Circulating Tumor Cell and Circulating Tumor DNA Assays for Diagnosis of Primary Lung Cancer. Anticancer Res. 2020 Jun;40(6):3435-3444.
For research use only. Not for use in diagnostic procedures.
